LMJTAB881143M-L RJ45 Modular Jack 10/100 Base-T Magnetic Connector LPJ4025-7ABNL

Name: LMJTAB881143ML RJ45 Modular Jack 10100 BaseT Magnetic Connector LPJ40257ABNL
Brand: LINK-PP
Price: 0.05 USD

Brand Name : LINK-PP

Model Number : LMJTAB881143M-L

Certification : UL,ROHS,Reach,ISO

Place of Origin : China

MOQ : 50/500/1000/25K

Price : $0.05-$1.28

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 4200K-PCS/Month

Delivery Time : Stock

Packaging Details : 50pcs/tray,1200pcs/carton

Part Number : LMJTAB881143M-L

Samples : Active&Available

Category : RJ45 Modular Jack

Latch : Tab Down

TURNS RATIO : 1CT:1CT & 1CT:1CT

Made In China : LPJ4025-7ABNL

Contact Now

LMJTAB881143M-L RJ45 Modular Jack 10/100Base-T Magnetic Connector LPJ4025-7ABNL

LMJTAB881143M-L
Trader Part Number	LMJTAB881143M-L
Made in China	LPJ4025-7ABNL
Manufacturer	LINK-PP China
Description	RJ45 Modular Jack
Documents Available	PDF/3D/Step/IGS/Price/Cross
Quantity Available	200,000 PCS or 3 weeks

NOTES:

1.Designed to support application,such as SOHO(ADSLmodems),LAN-on- Motherboard(LOM),hub and Switches.

2.Meets IEEE 802.3 specification

3.Connector Materials:

Housing: Thermoplastic PBT+30%G.F UL94V-0

Contact: Phosphor Bonze C5210R-EH Thickness=0.35mm

Pins: Brass C2680R-H Thickness=0.35mm

Shield: SUS 201-1/2H Thickness=0.2mm

Contact plating: Gold 6 micro-inches min.In contact area.

4.Wave solder tip temperature: 265℃ Max, 5 Sec Max

Applications For Terminal User

Used for networking and communication equipments such as HUB, PC card, Switch, Router, PC Mainboard, SDH, PDH, IP Phone, xDSL modem,Call Center solutions , Complex set top boxes , VOIP gateways setup,Border Gateway Protocol,fast ethernet switch ...
